Customized Pneumatic House Paint Sprayer - Eco Friendly & Long Lasting
Product Specifications
| Attribute |
Value |
| Grade |
Industrial |
| Power Source |
Pneumatic |
| Customized Support |
OEM, OBM, ODM |
| Place of Origin |
Shandong, China |
| Brand Name |
Zhongren |
| Model Number |
ZRM-1234/ZRM9C/ZRM-2546/ZRM-2832/ZRM-2840/ZRM-Q2 |
| Type |
Airless Spray Gun |
| Application |
Paint Spray Gun |
| Usage |
Nuclear and conventional power facilities/Pipeline/Metals and mining |
| Feature |
High Spraying Effect |
| MOQ |
1pcs |
| Pressure Ratio |
32:1-46:1 |
| Cylinder Bore |
125-280mm |
| Packing |
Wooden box |
Product Description
Factory Price Marine Pneumatic Anti-corrosion Epoxy Paint Spraying Machine High-pressure Airless Paint Sprayer.
The single component pneumatic airless sprayer offers the ultimate combination of power and portability, designed for spraying tough materials in challenging situations and approved for hazardous locations. These high quality, high volume and high pressure pneumatic airless sprayers are ideal for protective coating projects including bridges, ship tanks, and touch-up projects.
The system provides exceptional output values, pressure ratios and pumping capacities that outperform and outlast other sprayers in its class. Capable of handling the toughest protective coatings, corrosion control, waterproofing and fireproofing materials. Features a reliable air exchange valve for quick changeover and reduced pulsation.
Pneumatic Spraying Airless Pumps - Protective Coating
Zhongren produces high-pressure pneumatic sprayers for industrial finishing and protective coatings. Available in various models and configurations, these sprayers are suitable for a wide range of medium-solid paint products and protective materials at high thickness.
Airless Equipment Capabilities
- Spray paint products at ambient temperature, with optional dilution for required viscosity
- Handle heated materials to decrease viscosity and atomize paint at lower pressure
- Recirculate heated product in high pressure hoses to maintain temperature during spraying pauses
- Reduce working pressure by 50% when using heated products (normal pressure up to 500 bar)
- Equipped with professional accessories for maximum efficiency: airless guns, spray nozzles, and high pressure hoses
Model Specifications
| Model |
ZRSM-PA1234 |
ZRSM-PA9C |
ZRSM-PA2546 |
ZRSM-PA2832 |
ZRSM-PA2840 |
ZRSM-PAQ2 |
ZRSM-PAQ4 |
ZRSM-PA6918 |
| Weight |
36KG |
80kg |
65KG |
88KG |
88KG |
88KG |
88KG |
88KG |
| Cylinder bore(MM) |
125 |
240 |
250 |
280 |
250 |
280 |
250 |
250 |
| Use compressed air |
0.3-0.6 |
0.3-0.7 |
0.3-0.7 |
0.3-0.6 |
0.3-0.6 |
0.3-0.6 |
0.3-0.6 |
0.3-0.6 |
| Pressure ratio |
34:1 |
32:1 |
46:1 |
32:1 |
40:1 |
48:1 |
48:1 |
48:1 |
| No-load flow(L/min) |
5.6 |
51 |
20.8 |
38 |
30 |
40 |
46 |
36 |
Air compressor configuration: 1m³ (Customers are required to buy their own)
Performance Features
High-Volume, High-Pressure Pumps: Engineered for exceptional performance in waterproofing, fireproofing, and other protective coatings.
Exceptional Pump Longevity and Efficiency: Specifically crafted for heavy-duty spraying applications, our AtlasPro Pump Modules are built to withstand the most challenging conditions. Incorporating the time-tested V-Packing set sealing design, these modules ensure consistent and reliable performance.
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are the manufacturer and help customers to buy more products together to export.
Q: Do you have any certificates?
A: Yes, we have got CE certificates.
Q: About your products, could you do it OEM?
A: Yes, OEM is workable for us, but with MOQ.
Q: How long is delivery time?
A: 7-15 days after confirmation of the order.
Q: How to delivery the goods?
A: 1. Delivery to your shipping agent's warehouse
2. By Express for small parcel
3. By Sea or By air to your door or to nearest seaport for bulk.
Q: Have you guarantee for your products?
A: Normally we provide one year guarantee for Motor and circuit board. When ordering can ready some spare parts together. For long-term customers, we will extend the warranty term.
Q: What can you buy from us?
A: All kinds of spraying equipment for building construction, Accessories, Power tool.
Q: Why should you buy from us not from other suppliers?
A: Have rich experience in export transportation, have strict requirements for product production, strong sense of team service, and solve customer's detailed work.
